- Maximum Regulating Pressure: 10 bar
- Port Size: 1/2″ BSP
- Electrical Connection: M12 – 8 pin; male connector power supply/control signal
- Control Signal: 4 – 20 mA
- For Fluid Type: Lubricated or non lubricated air, neutral gases
- Options:–
- Filter Efficiency Rating: 50 MICRON
- Minimum Ambient Temperature: 0 °C
- Maximum Ambient Temperature: +50 °C
- Hysteresis: ± 50mbar (factory set up)
- Power Supply Voltage: 24V DC ± 15% (Max. ripple 1V)
- Power Consumption:Max. 2.8 W with 24 V DC and constant changes of the control signal < 1.5 W without change of control signal
- Minimum Pressure Differential: 0 bar
- Maximum Pressure Differential: 12 bar
- Minimum Regulating Pressure:
- Maximum Flow Rate: 150 m3/hour
- Operational Life:> 50 Million changes of control signal steps
- Protection Mode: IP65
- Specifications Met:EN 61000-6-1: 2001 | EN 61000-6-2: 2001 | EN 61000-6-3: 2001 | EN61000-6-4:2001
- ATEX Specifications Met: –
- Materials of Construction: Silicon free
- Vibration Resistance: 30g (in all directions)
- Mounting Position:Indifferent (recommended position: upright; electronic part on top)
