Technical features
Medium:
Compressed air
Operating pressure:
15 bar (218 psi) maximum
Thread sizes
M5, 1/8″, 1/4″, 3/8″ or 1/2″
Ambient/Media temperature:
-18 … +70°C (-0,4 … +158°F)
Tube sizes:
4/2,5 mm, 5/3 mm, 6/4 mm, 8/6 mm, 10/8 mm, 12/10 mm, 15/12,5 mm OD/ID
Tubing types:
PUR or PA extra flexibility
Materials:
Nut and body: Nickel plated brass to OT58 UNI 5705
O-ring: NBR 70
Sealing washer: PA 33
